Shop HeatSync™ and Generation 4 Aurora Series®
Aurora® Ultimate™ 25×75 XT C18 UHPLC column
Aurora® Ultimate™ 25×75 XT C18 UHPLC column
25 cm x 75 μm C18 UHPLC packed emitter column with built-in HeatSync™ technology, compatible with EASY-Spray, Nanospray Flex, and Newomics UniESI and DuoESI ion sources.
| SPD | 10 - 40 |
|---|---|
| Gradients | 45 - 120 mins |
| Recommended flow rate | 100 - 400 nL/min |
Aurora® Ultimate™ 25×75 XT C18 HeatSync™ Starter Pack
The original game-changer.
The pinnacle of chromatography performance while minimizing overall cost and stress on equipment. Want it all? The Aurora Ultimate™ continues the legacy of IonOpticks’ original 25 cm UHPLC line, delivering maximum peak capacity when time is less of a determining factor, but still a consideration.
Product Benefits:
- Extreme coverage and sensitivity without excessive time
- Unlocks the true power of your mass spectrometer
Spectacular protein IDs.
Every run. Every time.
Deep proteome coverage.
Maximise the number of identifications that you can achieve from a single shot sample analysis.
Figures 1, 2 & 3: Identified unique proteins, peptides and average Full Width at Half Maximum (FWHM) from 200 ng HeLa Tryptic Digest injection on an Aurora Ultimate™ 25 cm x 75 μm column using different gradient lengths. Samples were run on a Waters ACQUITY UPLC M-Class coupled to a Bruker timsTOF Pro, dia-PASEF acquisition. Data analysed using DIA-NN.
Figure 4: Yeast tryptic digest was spiked into a HeLa tryptic digest (200 ng) in different ratios (Sample A – 45 ng; Sample B – 15 ng). Samples were run on a Waters ACQUITY UPLC M-Class coupled to a Bruker timsTOF Pro, dia-PASEF acquisition using an Aurora 25 cm x 75 μm column. Data analysed using DIA-NN. Each point represents a unique protein with ratios calculated between the A and B samples. Figure 5: Boxplot demonstrating average ratio and interquartile range of data. Expected ratios are indicated with dashed lines.
High quantitative accuracy
Identify large numbers of unique proteins without compromising quantitative accuracy.
| Column format | Analytical column |
|---|---|
| Column type | Reversed-phase |
| For use with | UHPLC |
| Length | 25 cm |
| Inner Diameter | 75 µm |
| Pore size | 120 Å |
| Pressure | >1700 bar |
| Temp. limits | 60°C |
| Particle size | 1.7 µm |
| pH stability | 1–8 |
| Stationary phase | C18 |
